Oil Seeds Roster Steam Cooker (YZCL Series)

Product Overview

Industrical YZCL Multiple Layer Steam Cooker for Groundnut,Soya,Sunflower Oil Seeds
2020 Manufacture Price Industrical steam cooker for edible oil seeds

1.Oil Seeds Steaming Cooker Introduction:
YZCL180*5 Steaming Cooker is the processing equipment, with which the uncooked flaking billet is made to cooked billet by cooking after making humid. In order to meet the requirement the next pressing or leaching, the equipment could be used as softening cauldron. Oil seeds leaching culd improve the quality of flaking, and then improve the yield of oil, as well the quality of squeezd oil. Is the necessary equipment in vegetable oil seeds pre-processing for the vegetable oil plant the diameter.

2.Oil Seeds Steaming Cooker Specifications:

Suitable for roasting/drying different oil materials, such as rapeseed, peanut, soybean, sesame, cottonseed, coconut, palm embryo, etc. It is also used for conditioning the seeds before pressing to get the better pressing terms for oil seeds.
Its heatingsource is steamor conducting oil.

YZCL system steam cooker is a kind ofcontinuous steam cooking equipment, it mainly used to fry, wet, soften and heating the raw materials into cooked flakes through temperature and moisture to get better oil ouput in oil press machine and improve cake quality, its one of the most important part of the pre-pressing, pressing, solvent extraction plant.

The process is to add the hot water into the seeds crushed/flaked to moist, to add steams for steaming the seeds, to dry the seeds for ridding off more water content.
In the process, with the water and temperature to make the protein of seeds change the character, make the oil moleculeo loose for easily pressing to get rude oil, also get the better cake and oil.
The machine includes: cooker body, steam pipe & valves matched with cooker, motor, reducer, thermometer, pressure gauge.

FEATURES AT A GLANCE

Steam cooker for edible oil seeds Feature:

1. Perfect cooking function, and can adjust the raw materials moisture properly.
2. The quipment occupy small space, low voice , easy operation and simple operation.

Oil Seeds Roster Steam Cooker (YZCL Series)

Prouduction workshop

Final Products

Final Products we do in edible oil workshop

PRODUCT SPECIFICATIONS

Type	YZCL150x5	YZCL180x5	YZCL210x5	YZCL220x5	YZCL250x5
Capacity	25-30 T/D	35-50 T/D	50-80 T/D	70-90 T/D	90-120 T/D
Motor Power	18.5KW	22kw	30KW	30KW	37kw
Working pressure	0.7Mpa	0.7Mpa	0.7Mpa	0.7Mpa	0.7Mpa
Heating Area	14.6	19.7	23.6	25.6	35
Inter Diamater	φ1500	φ1800	φ2100	φ2200	φ2500
Layer	5	5	5	5	5
Reducer velocity	1:30	1:30	1:30	1:40	1:40
Main Rotation	33rmp/min	33rmp/min	24rmp/min	24rmp/min	24rmp/min
Reducer type	ZCL1:30	ZCL1:30	ZCL1:40	ZCL1:40	ZCL1:40
Motor type	Y200L1-6	Y200L1-6	Y225L1-6	Y225L1-6	Y250M-6
Overall dimensions	4710	4710	4710	4850	4850
Weight	5850kg	7000kg	8700kg	10000kg	13000Kg

PRODUCT CONFIGURATION

big oil press machine 200TPD

Prepress oil press machine 70-80TPD

Oil press machines for press 30-50TPD

Successful Project

Project have done

Project in China

Project in Uzbekistan
